5KW Bottle Filling Capping And Labeling Machine For 5-30ml E-Cigarette

Basic Information
Place of Origin: Shanghai
Brand Name: METICA
Certification: CE
Model Number: MTFC-1000
Minimum Order Quantity: 1 SET
Price: USD 10000-30000/SET
Packaging Details: Fumigation-free wooden boxes that meet international standards
Delivery Time: 25-30 days
Payment Terms: L/C, T/T
Supply Ability: 100 SETS PER MONTH
Detail Information
Name: E-Cigarette Filling Machine Line Application: For E-Cigarette, Pharmaceutical, Health Care Industries
Capacity: 2000-3000 BPH(related To Filling Volume) Filling Accuracy: More Than 99%
Length Of The Line: Around 8000 Mm Warranty: One Year
Workflow: Feeding-filling-capping-labeling-collecting Voltage: 110V/220V,50/60HZ
Type: Filling Machine, E-Cigarette Bottling Line Bottle Type: Small Plastic Bottle And Glass Bottle
High Light:

Bottle Filling Capping And Labeling Machine


5KW Filling Capping And Labeling Machine


30ml filling capping labeling machine

Product Description

Automatic 5-30ml E-Cigarette Filling Capping Labeling Line Bottling Production Line


Application :

  • The filling capping and labeling machine is widely used in Essential oil, CBD oil, E-Cigarette, Pharmaceutical, Health Care industries.
  • This vial filling capping and labeling machine is suitable for small volume 10-100 ml liquid automatic packing, like CBD oil, Essential oil, E-Cigarette Oil, Eye Drop, Oral Liquid and so on.


the Whole Line technical parameter

  • Bottle applied: Round glass dropper bottle or round plastic bottle
  • Line speed: 2000-3000 bottles per hour
  • Filling volume: 10-100 ml (can be customized)
  • Power: about 5KW
  • Air pressure and consumption: 0.6-0.8Mpa


Spec and Feature

  • The whole machine line is designed especially for 10-100ml liquid filling, capping, labeling
  • The line speed is 20-35 bottles per minute
  • Filling plugging-in and capping machine in one machine, save space and away from pollution
  • Famous branded electrical parts guarantee the line working stable and a longer working life
  • Adopts peristaltic pump or piston pump for filling, high filling precision. No bottle, no fill, no drop, no leak
  • Touch screen, easy operate and adjust human interface. English or other language operation interface
  • The machines can work together smoothly or work alone by PLC control
  • The line is easy to install, operate, maintenance, and move
  • Suitable for different diameter bottles, just need several minutes change parts for different bottles
  • All the machine parts which contact liquid adopt corrosion resisting material and 316 stainless steel
  • The machines have emergency stop Button and automatic interrupt device for safe operation
  • Labors need: 1-2 workers
  • Space for the line: 8000*1500*1900mm


5KW Bottle Filling Capping And Labeling Machine For 5-30ml E-Cigarette 0


Samples display:

5KW Bottle Filling Capping And Labeling Machine For 5-30ml E-Cigarette 1
